Home ProductsFlexo Printing MachinePRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker

PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker

PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker
Basic Information
Place of Origin: China
Brand Name: PRINTYOUNG
Certification: CE
Model Number: PRY-D-400
Minimum Order Quantity: 1 Set
Price: US 85000 Set
Packaging Details: Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 Set/Sets per Month
Contact Now
Max Paper Size: 1200 * 2400 Mm Min Paper Size: 300 * 600 Mm
Max Printing Size: 1200 * 2200 Mm Printing Thickness: 3 ~ 11 Mm
Working Speed: 80 ~ 120 Pcs/min The Inside Width Of Machine: 2600 Mm
Printing Precision: ± 0.75 Mm Printing Plate Thickness: 6 Mm
Roller Axial Adjustment: ± 2.5 Mm Roller Circumferential Adjustment: 360°

PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 0
PRY-D400 Printing Slotting Die-Cutting Machine
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 1
Features
※ Use lead edge feeding unit with absorption system on the table,can let the curved board pass smoothly.
※ Drive gear is helical gear system.
※ Printing unit and slotting unit are adjusted by electrical digital 360 degree,reduce time and improve work efficiency.
※ Frequency motor drive,customer s can adjust the speed freely in the range.
※ The gap of printing roller with big adjusting range,it is fit for three,five,seven layer with different thickness paperboard with high printing precision.
※ This machine use electrical separable structure,customers can achieve single color,double color printing,easy for maintenance,with pneumatic locking,separate position,operation quickly and conveniently.
※ All the motor are made in China.Customers need to inform us advance if need other brand motor.
Technical Parameters
PRY-D400 Printing Slotting Die-Cutting Machine
Machine Model
PRY-D400
Max Paper Size
1200 * 2400 mm
Min Paper Size
300 * 600 mm
Max Printing Size
1200 * 2200 mm
Printing Thickness
3 ~ 11 mm
Working Speed
80 ~ 120 pcs/min
The Inside Width of Machine
2600 mm
Printing Precision
± 0.75 mm
Printing Plate Thickness
6 mm
Roller Axial Adjustment
± 2.5 mm
Roller Circumferential Adjustment
360°
Configuration
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 2
★ Lead Edge Feeder
※ The lead edge feeder reduces the paperboard plug a lot.
※ The fan helps for feeding paper,ensure the curved feeding,the air volume can be adjusted according to the paper size,make sure the pull of vacuum for paper,improve the feeding precision.
※ The side wallboard is electrical adjusting,the front and back are manual adjusting.
※ The feeding wheel is made of polyurethane,with big friction and long service life.
※ It is used for three,five layer corrugated board,include B type paperboard.
※ The feeding counter,set and show the produce number.
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 3
★ Printing Unit (4 part)
※ The printing roller surface is hard chromium plating and polished,make it work stable
※ The uniforming roller is coated with abrasive rubber,the mid-high is parabola type for compensating the forced deformation,improve the ink transmission.The rubber is Nitrile rubber,hardness above 60 degrees,good effect for supplying ink after special polished. The rubber roller is driven by motor when the machine stop,machine stop and continuous supplying ink,auto uniform ink.
※ The anilox roller is from famous domestic brand,the rollers are made by mature technology,the cylinder is less 0.016mm,radial circle run out is less than 0.1mm,with 25 times the magnifier for the overlapping curve,margin,and the micro hardness of HV900-1050.So it is good at store,uniforming and transmission ink,it is the best choice for printer.(The anilox roller mesh is depends on customer)
※ The electrical phase adjustment device,make the machine adjusted longitude 360°when work or stop,saving change time.
※ The pneumatic diaphragm pump circulating supply ink,operation and maintenance easy.
※ Use pneumatic lifting plate,auto even ink,stop machine continuous supplying ink, avoid the ink drying when machine stop,reduce the disadvantageous factor for printing effect.
※ The printing roller equipped with hanging function,saving time for change plate.
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 4
★ Slotting Department
Pressing Line Wheel
※ Adopt seamless steel tube,after two times grinding machining,surface of the roller is chromed,move steadily.
※ The pressing line wheel gap adopts manual adjustment,the adjusting range is 0~11mm.
The Slotting Knife Lateral Shift Adjustment Structure
※ Adopt seamless steel tube,after two times grinding machining,surface of the roller is chromed,move steadily.
※ The width of slotting knife is 7.0mm.
※ The slotting knife adopt alloy steel.It also has gone through heat treatment and grinding,the knife sharp is saw tooth.Both the rigidity and toughness are very good.
※ The repair edge knife adopt alloy steel and has gone through heat treatment and grinding,the knife is sharp and high precise.
※ The slotting knife seat gap adopts manual adjustment,the adjusting range is
0~11mm.
※ Two slotting knives adopt manual synchronous adjustment.(the box height)
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 5
★ Die-Cutting Unit
Cutter Die Roller(down roller)
※ Cast iron material surface grinding,hard chromium plating,balance correction, increased running stability.
※ Cutter die fixing screw hole spacing,axial 100mm,radial direction 20 divide from the middle,adapt cutter die hight 25.4mm
※ Wood template thickness:
16mm(3 layer cardboard use);13mm(5 layer cardboard use)
Rubber Pad Roller(top roller)
※ Quick change type rubber pad,wear-resisting,long life.
※ Cast iron material surface grinding,hard chromium plating.
※ Balance correction,increased running stability.
※ Electric type adjustment and cutter die roller clearance,adjustment range 0-16mm.
※ Rubber pad thickness 9mm,width 250mm
※ Mechanical type transverse 40mm move device (can adjustment move speed).

Main Drive Gear

1.High-precision straight gear transmission,big gear adopt high quality spheroidal graphite, little gear adopt 45# alloy steel,by gear quenching processed forming,the drive gear intensity will enhance,good abrasion resistance,smooth transmission.
2.Shaft and gear connection adopt tension connecting sleeve,keyless connection,there will be no clearance when using big torque,nstallation and maintenance more convenient,long-term transmission precision is high,guarantee printing chromatically accurate,lubrication adopt oil pump automatic spray lubrication system,ensure transmission accuracy life.
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 6
★ Stacker Machine
Sheet Laying Arm
※ Option for manual or automatic operation.
※ Independent tension adjustment of transmission belt of sheet laying arm is not limited by the equal length of belts.
Lifting of Machine
※ Driven by mighty chain.
※ Height of piling is 1600mm.
※ Machine lifting transmission motor added with brake realizes the fixed position of machine bed without sliding.
※ Added with safety facility to control the lifting of machine and secure the worker.
※ Climbing belt with wrinkled surface prevents sliding of paperboard.
Sheet Laying Baffle
※ Pneumatic sheet laying baffle automatically reaches out to receive and support paperboard when the piled paperboard reaches the height preset.
※ Back baffle position is adjusted by manual control.
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 7
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 8
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 9
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 10
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 11
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 12
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 13
PRY-D400 Automatic Lead Edge 4 Colors Flexo Printing Slotting Die Cutting Machine with Stacker 14
Q1.Are you a manufacturer or a trading company?
A:Our shanghai office is mainly doing export.We have our own factory in Wenzhou,Zhejiang Province.
Q2.What is the machine warranty?
A:One year.After the warranty,we still provide technical support to buyer at low cost.
Q3.What is the production time while placing order?
A:Normally about 10-20 days.
Q4.What is the delivery time?
A:15-30days after deposit.
Q5.Can your company handle shipping for customers?
A:Yes,just give us destination sea port or container yard.
Q6.Does the packing strong?
A:Yes.Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions.A full set of maintenance and operation manuals is included.
Q7.How about the machine installation and training?
A:1)We provide training in our factory for free; 2)We can send technicians (engineers) to your factory for installation and training.You shall pay the round trip air fare and accommodations,plus each technician charges USD100/per day.
Q8.Do you have machines in stock?
A:For standard model,we have a large quantity in stock.For special model,we need 20-30 days to produce it for you.
Q9.How can you assure the machines’ quality?
A:Each machine will be test running at least 24 hours before delivery to assure the quality.And during the warranty,we will give spare parts for free if machine has any problem.
Q10.Do you inspect machines or test running before packing?
A:Of course we do.We have QC department to debug the machine before packing.If you want to use specific material to do the test running,you need to pay for the cost of the material.
Q11.What’s the payment term?
A:T/T 30% in advance,the balance shall be paid before delivery.We also accept payment by West Union or L/C at sight.
Q12.Do you accept factory visiting?
A:Warmly welcome for your visiting.
Q13.How many years are you in printing field?
A:The Shanghai company since in 2008,the factory is more than 25years.
Q14.How many clients do you have?
A:We have sold our machines to about 60 countries.We have agents in South Africa,Morocco and Italy.
