PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine

PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine
Basic Information
Place of Origin: China
Brand Name: PRINTYOUNG
Certification: CE
Model Number: PRY-1000-6
Minimum Order Quantity: 1 Set
Price: US 70000 Set
Packaging Details: Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Delivery Time: 60 days
Payment Terms: L/C, T/T
Supply Ability: 10 Set/Sets per Month
Contact Now
Color & Page: 6 Colors Weight: 10000 KG
Print Dimension: 1000 Mm Print Speed: 150 M/min
Unwinding Diameter: 1500 Mm Rewinding Diameter: 1200 Mm
Printing Repeat: 380 - 1300 Mm Max Feeding Width: 1050 Mm
Max Printing Width: 1000 Mm Paper Thickness: 50 ~ 300 Gsm
Printing Plate Thickness: 1.7 Mm Double Glue Tap Thickness: 0.38 Mm
Printing Precision: ± 0.15 Mm Machine Speed: 0 ~ 150 M/min

PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 0
PRY-1000-6 Unit Type Flexo Printing Machine
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 1PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 2
Technical Parameters
PRY-1000-6 Unit Type Flexo Printing Machine
Unwinding Diameter
1500 mm
Rewinding Diameter
1200 mm
Printing Repeat
380 ~1300 mm (133T ~ 472T)
Max Feeding Width
1050 mm
Max Printing Width
1000 mm
Machine Body Thickness
58 mm
Paper Thickness
50 ~ 300 gsm
Weight
10000 kgs
Gear Pitch
1/8 inch (3.175 mm)
Printing Plate Thickness
1.7 mm
Double Glue Tap Thickness
0.38 mm
Printing Precision
± 0.15 mm
Power Supply
380V 3PH 50Hz
Total Power
140 kw (including external hot air 22 kw)
Machine Speed
0 ~ 150 m/min
Air Compressor
100 PSI (0.6 Mpa)
Main Motor
11 kw
Tension Area
5 ~ 50 kg
Rewinding Motor
7.5 kw
Unwinding Traction Motor
3 kw
Configuration
1.Shaft-less unwinding unit
• Automatic loading/unloading by hydraulic
• Unwinding tension is controlled by pneumatic brake + automatic tension control system
• Auto stop when paper roll is finished
2.Auto web guiding
• With pneumatic splicing table
• The paper guide roller adopts high hardness anodized
• Adopt the ball screw electric actuators
• Ultrasonic sensor,system can correct when paper goes skewing
• Detection mode:check the edge
• Precision:±0.12mm
3.In/Out-feeding system
• Rubber rollers for feeding
4.Printing unit 6 units
• Pneumatic for opening and closing anilox roller and printing roller
• Ceramic anilox roller.1 pcs per printing unit,customized
• Printing roller.1 pcs per printing unit,customized(Steel material less than 130T,aluminum material more than 131T)
• Stainless steel ink box,single doctor blade
• Adopts petal structure,the pressure is stable,and the printing cylinder can be changed fast
• Printing plate automatically cleaning function:printing roller keeps rotating for 1.5s to pass the ink to paper when machine is stopped each time,it can make plate clean
• Anilox roller rotate itself function:anilox roller will rotate itself when machine is stopped, to avoid ink dry on face of anilox roller
• Gear mode:cp1/8,material 20CrMnTi,long working life
5.Drying system
• IR
• Hot air
6.Video camera
7.Surface rewinding unit
• Automatic tension control system by vector motor + inverter
• Automatic loading/unloading by hydraulic
• Stop when paper is cut off
8.Auto stopping function
• Pre-set printig meter, and machine will stop automatically
9.Venison plate mounter
10.Touch screen
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 3
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 4
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 5
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 6
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 7
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 8
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 9
PRY-1000-6 Unit Type Paper Cup Six Color Flexo Printing Machine 10
Q1.Are you a manufacturer or a trading company?
A:Our shanghai office is mainly doing export.We have our own factory in Wenzhou,Zhejiang Province.
Q2.What is the machine warranty?
A:One year.After the warranty,we still provide technical support to buyer at low cost.
Q3.What is the production time while placing order?
A:Normally about 10-20 days.
Q4.What is the delivery time?
A:15-30days after deposit.
Q5.Can your company handle shipping for customers?
A:Yes,just give us destination sea port or container yard.
Q6.Does the packing strong?
A:Yes.Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions.A full set of maintenance and operation manuals is included.
Q7.How about the machine installation and training?
A:1)We provide training in our factory for free; 2)We can send technicians (engineers) to your factory for installation and training.You shall pay the round trip air fare and accommodations,plus each technician charges USD100/per day.
Q8.Do you have machines in stock?
A:For standard model,we have a large quantity in stock.For special model,we need 20-30 days to produce it for you.
Q9.How can you assure the machines’ quality?
A:Each machine will be test running at least 24 hours before delivery to assure the quality.And during the warranty,we will give spare parts for free if machine has any problem.
Q10.Do you inspect machines or test running before packing?
A:Of course we do.We have QC department to debug the machine before packing.If you want to use specific material to do the test running,you need to pay for the cost of the material.
Q11.What’s the payment term?
A:T/T 30% in advance,the balance shall be paid before delivery.We also accept payment by West Union or L/C at sight.
Q12.Do you accept factory visiting?
A:Warmly welcome for your visiting.
Q13.How many years are you in printing field?
A:The Shanghai company since in 2008,the factory is more than 25years.
Q14.How many clients do you have?
A:We have sold our machines to about 60 countries.We have agents in South Africa,Morocco and Italy.
