Place of Origin: | China |
---|---|
Brand Name: | PRINTYOUNG |
Certification: | CE |
Model Number: | PRY-JD260 |
Minimum Order Quantity: | 1 Set |
Price: | US 28000 Set |
Packaging Details: | Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included. |
Delivery Time: | 45 days |
Payment Terms: | L/C, T/T |
Supply Ability: | 30 Set/Sets per Month |
Machine Type: | Bag Forming Machine | Bag Type: | Food Bag |
---|---|---|---|
Material: | Paper | Applicable Industries: | Manufacturing Plant |
Showroom Location: | Egypt, Italy, Algeria, South Africa, Morocco | Place Of Origin: | Zhejiang, China |
Weight: | 3500 KG | Warranty: | 1 Year |
Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
Max Speed: | 600 Pcs/min | Condition: | New |
Computerized: | Yes | Voltage: | 380 V |
Dimension: | 6000 * 1600 * 1800 Mm | Cutting Length: | 120 - 400 Mm |
Bag Length: | 100 - 380 Mm | Bag Width: | 80 - 250 Mm |
Insert Size: | 20 - 110 Mm | Ladder Height: | 15 - 18 Mm |
Paper Width: | 160 - 780 Mm | Maximum Diameter Of Paper Material: | 1000 Mm |
Inner Diameter Of Paper: | 76 Mm | Paper Thickness: | 45 - 80 Gsm |
Working Gas: | > 0.12 M³/min , 0.5 - 0.8 Mpa | ||
Highlight: | Sharp Bottom Paper Bag Forming Machine,Paper Bag Making Forming Machine 380V,80gsm Food Paper Bag Making Machine |
Model
|
PRY-JD260
|
|
---|---|---|
Cutting Length
|
120 - 400 mm
|
|
Bag Length
|
100 - 380 mm
|
|
Bag Width
|
80 - 250 mm
|
|
Insert Size
|
20 - 110 mm
|
|
Ladder Height
|
15 - 18 mm
|
|
Paper Bag Speed
|
100 - 600 pcs/min
|
|
Paper Width
|
160 - 780 mm
|
|
Maximum Diameter of Paper Material
|
1000 mm
|
|
Inner Diameter of Paper
|
76 mm
|
|
Paper Thickness
|
45-80 g/m2
|
|
Working Gas
|
≧ 0.12 m³/min , 0.5 - 0.8 mpa
|
|
Power
|
380 V 3 phase 4 line 12 kw
|
|
Total Weight
|
3500 kg
|
|
Outline
|
6000 * 1600 * 1800 mm
|
