Automatic Two Side Seal Bubble Mailer Making Machine PRY-800

Automatic Two Side Seal Bubble Mailer Making Machine PRY-800
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 Automatic Two Side Seal Bubble Mailer Making Machine PRY-800
Basic Information
Place of Origin: China
Brand Name: PRINTYOUNG
Certification: CE
Model Number: PRY
Minimum Order Quantity: 1 Set
Price: US 42500 Set
Packaging Details: Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Delivery Time: 45 days
Payment Terms: L/C, T/T
Supply Ability: 10 Set/Sets per Month
Contact Now
Applicable Industries: Manufacturing Plant Machine Type: Bag Forming Machine
Material: Paper,film Model Number: PRY-800
Voltage: 380V Dimension: 23000*2300*2100mm
Weight: 7000 KG Max Speed: 100cuts/min
Application: Coated Kraft Paper(80-130g/sqm), PE Bubble Film The Max Bag Length: One Big Size 760mm( Include The Tongue)
The Max Bag Width: 600mm The Max Material Roll Width: 1550mm
The Max Material Roll Diameter: Kraft Paper 1400mm, PE Bubble 1400mm Power: 3-phase 4-lines AC 380V 50-60HZ 36KW
Overall Dimension: 23000*2300*2100mm
High Light:

Bubble Mailer Envelope Making Machine

,

Poly Mailer Making Machine 600mm

,

Mailer Bag Making Machine 36KW

Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 0
PRY-800 Automatic Two Side Seal Bubble Mailer Making Machine
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 1
Features
The machine has such features as:computer controlled,imported two servo motor for traction the material, unwinding material in constant tension,photoelectrical correct the error,when the sign is loose or there is no material the machine will stop automatically,etc and stop in high position.
1.Main control:adopt PLC control,LCD display,servo motor fix the bag length.With functions:auto counting, alarm and auto stop when reach the set bag number,stop in high position,etc.No material will auto stop.
2.Infeed part:adopt active following type,control the up and down layer material feed respectively,the speed be controlled by the vector frequency inverter.
3.Material combine:electric heating rolling jumbo roll compound paper with PE bubble film strong and smooth in full surface.
4.Equipped with pneumatic slitting blade:can make two small bags at one time.(when each one sealing width <350mm)
5.inductive conveyer belt:2meters long move slowly,when reach setting batch no will move faster so there is a gap easy for pack
6.hole puncher:you can choose the hole diameter and shape
7.Additional Hot Melt Glue Line for making Glue Line Tape(2 Heads for making 2 at a time)
Technical Parameters
PRY-800 Bubble Mailer Making Machine
Application
coated kraft paper(80-130g/sqm), PE bubble film
The max speed
for paper bubble mailer 100cuts/min,For poly bubble mailer 60cuts/min
(note:it is the machine’s highest speed,the production speed will depend on the bag size,the thickness of material and the time of be sealed)
The max bag length
One big size 760mm( include the tongue)
When make two each max be 380mm
The max bag width
600mm (when width < 500mm can be press three time.
If over 500 press by two time)
The max material roll width
1550mm
The max material roll diameter
Kraft paper ￠1400mm, PE bubble ￠1400mm
Power
3-phase 4-lines AC 380V 50-60HZ 36KW
Weight
about 7T
Overall dimension
23000*2300*2100mm(L*W*H) for reference
Configuration
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 2
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 3
Unwind station paper or poly film with pneumatic lifer and auto tension controller on air shaft.bubble roll on normal shaft with EPC control(edge position controller)
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 4
bubble storage system
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 5
poly film laminate
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 6
paper laminate
Heat compounding station heat by oil
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 7
Folding station which Can fold one side or fold two side to make two pcs one time
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 8
With folding edge control system to ensure edge be exact position during machine running
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 9
Servo drive traction with green belt keep material constant tension and move smooth forward
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 10
Heating sealing part:4 SETS
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 11
Cooling bar *1
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 12
Glue spray system 8 kg TANK
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 13
With glue gap control by PLC can setting gap distance
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 14
release paper unwind roll which drive by small motor . put two rolls one time.to make 2 bags
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 15
Pneumatic High strength Circle Slitting knife to make two pcs at same time for paper
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 16
Cutting knife and Inductive Conveyor belt
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 17




Applications
This machine used to make the mail bag from kraft paper and poly bubble lining.It combine coated kraft paper together with that PE bubble film by the heating jumbo roll.Be formed under the first press of the horizontal heat-seal bar,then after a second press of the cooling bar will be more even and firm,at last be cut at the fixed length to be the finished mail bag.
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 18
Paper bubble mailer
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 19
poly bubble mailer(OPP+PE)
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 20
PE bubble mailer
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 21
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 22
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 23
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 24
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 25
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 26
Automatic Two Side Seal Bubble Mailer Making Machine PRY-800 27
Q1.Are you a manufacturer or a trading company?
A:Our shanghai office is mainly doing export.We have our own factory in Wenzhou,Zhejiang Province.
Q2.What is the machine warranty?
A:One year.After the warranty,we still provide technical support to buyer at low cost.
Q3.What is the production time while placing order?
A:Normally about 10-20 days.
Q4.What is the delivery time?
A:15-30days after deposit.
Q5.Can your company handle shipping for customers?
A:Yes,just give us destination sea port or container yard.
Q6.Does the packing strong?
A:Yes.Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions.A full set of maintenance and operation manuals is included.
Q7.How about the machine installation and training?
A:1)We provide training in our factory for free;
2)We can send technicians (engineers) to your factory for installation and training.
You shall pay the round trip air fare and accommodations,plus each technician charges USD100/per day.
Q8.Do you have machines in stock?
A:For standard model,we have a large quantity in stock.For special model,we need 20-30 days to produce it for you.
Q9.How can you assure the machines’ quality?
A:Each machine will be test running at least 24 hours before delivery to assure the quality.
And during the warranty,we will give spare parts for free if machine has any problem.
Q10.Do you inspect machines or test running before packing?
A:Of course we do.We have QC department to debug the machine before packing.
If you want to use specific material to do the test running,you need to pay for the cost of the material.
Q11.What’s the payment term?
A:T/T 30% in advance,the balance shall be paid before delivery.We also accept payment by West Union or L/C at sight.
Q12.Do you accept factory visiting?
A:Warmly welcome for your visiting.
Q13.How many years are you in printing field?
A:The Shanghai company since in 2008,the factory is more than 25years.
Q14.How many clients do you have?
A:We have sold our machines to about 60 countries.We have agents in South Africa,Morocco and Italy.
