|Max. Paper Size:||1080*780mm||Min. Paper Size:||400*330mm|
|Max.die Cutting Size:||1070*770mm||Max. Foil Stamping Size:||1060*760mm|
|Name:||Paper Sheet Cutting Machine||Model:||AEM-1080T|
paper sheet cutting machine,
creasing and die cutting machine
Servo Motor Paper Sheet Cutting Machine Foil Stamping Machine CE Certification
AEM-1080T Automatic hot stamping and die cutting machine is used for hot stamping and die cutting various paper, paperboard, corrugated board, plastic sheet(like PVC, PP), with function of foil hot stamping, holographic hot stamping, die cutting & creasing and embossing. It adopts server motor to control the foil stamping, feeding and collecting. Temperature control system has 12 heating area, temperature setting separately, and thermostatic control.
|Max. Paper size||1080*780mm|
|Min. Paper size||400*330mm|
|Max.die cutting size||1070*770mm|
|Die frame inner size||1100*790mm|
|Cutting plate size||1080*780mm|
|Max. Foil stamping size||1060*760mm|
|Min gripper needle size||7mm|
|Foil stamping precision||≦±0.125mm|
|Max. cutting pressure||300T|
|Max. cutting speed||7000s/h|
|Max. Foil roll diameter||Ф250mm|
|Vertical foil roll width||15-1060mm|
|Horizontal foil roll width||15-760mm|
|Vertical foil roll shaft||3pcs|
|Horizontal foil roll shaft||2pcs|
|Controllable temperature area||12pcs|
|Collection stack height||1500mm|
|Main motor power||11Kw|
|Heating area power||24Kw|
1. Foil device adopt high wear-resisting polyurethane, ensures stable and reliable running
2. Dual foil detection system to check on real-time.
3. Separate foil recycle device mixed recycle box to make operation fast and easily.
4. Foil holder with movable design, can push out of machine for place the foil easily and fast.
5. Adopt transverse foil placement device, easy and convenient
6. Static elimination device to make paper smooth and accurate
7. Longitudinal foil roll with rational distribution and servo drive
