Computer Rotogravure Thermal Rotogravure Printing Machine , Multifunction Paper Roll Printing Machine

Basic Information
Place of Origin: China
Certification: CE
Model Number: ZMA94B
Minimum Order Quantity: 1 Set/Sets
Packaging Details: Daub rust-proof oil, then wrap stretch film, and then fixed inside the container
Delivery Time: 5-10 days stock,20-60 days unstock
Payment Terms: L/C, T/T, Western Union
Type: Rotogravure Printing Machine Usage: Wine Label Cig Label
Automatic: Automatic Grade Feeder: Heidelberg-type
Stacking Height: 1500mm Paper Material: White Board Copper
Collection Roller: Double Size Cylinder With Anti-smearing Coating Optional: UV Or Water-base Coating
Delivery: Underside Feeding Swing Arm Dryer: Hot Wind And IR Drying
High Light:

gravure printing press


web offset printing machine

            Computer Rotogravure Thermal Multi-functional Paper Roll Printing Machine


This press is an automatic gravure press with excellent performance, easy operation, stable and reliable quality. It also can varnish sheet with varnishing oil. This press has the advantages of multi-type and short run jobs. It can combine together with the printing technologies of offset printing, flexographic printing and process printing. This model is suitable for printing exquisite packaging, decoration prints, alcohol label, cigarette label, cosmetics box, etc.


 Technical Parameter


Model ZMA94B
Max. sheet size 650×940mm
Min. sheet size 393×546mm
Max. printing area 630×940mm
Max. speed 10000pcs/h
Thickness(weight) of paper 0.07~0.45mm
Feeder pile height 1500mm
Delivery pile height 1000mm
Power of main motor 7.5kw
Overall power 80kw
Overall dimensions 9600×4000×2700mm
Machine weight 9100kg




 Patented Underside Feeding Swing Arm; Underside Front Lay


 Heidelberg-type Feeder of 1500mm Stacking Capacity;


 Non-stop Feeder and Delivery


Patented Plate Cylinder Loading Mechanism


Double Size Delivery Cylinder with Patented Anti-smearing Device


Air Clutch for Cylinders and Scraping Blade


Hot wind and IR drying for high printing speed.


 Electric Ink Pump Driven by Explosion-proof Motor


 Double Size Impression Cylinder


 Centralized Automatic Lubricating System


 Hot Wind and IR Drying for High Printing Speed; UV Curing System Optional
