| Place of Origin: | China |
|---|---|
| Brand Name: | PRINTYOUNG |
| Certification: | CE |
| Model Number: | YH-1300 |
| Minimum Order Quantity: | 1 Set/Sets |
| Price: | negotiation |
| Packaging Details: | Packed in carton firstly,and then reinforced with wooden case for outer packing |
| Delivery Time: | 30 working days after received your payment |
| Payment Terms: | T/T or western Union |
| Supply Ability: | 30 sets per month |
| Max. Paper Size: | 1320×950 Mm | Min. Paper Size: | 550×450mm |
|---|---|---|---|
| Max. Die-cutting Size: | 1310×940mm | ||
| High Light: | paper die cutters,creasing and die cutting machine |
||
11KW Paper Die Cutting Machine Rotary Plastic Adhesive Label Roll
Specifications :
| Die-cutting ways | flat to flat (with upper platen fixed and lower platen movable) |
| Max. Paper Size | 1320×950 mm |
| Min. Paper Size | 550×450mm |
| Max. die-cutting Size | 1310×940mm |
| Min gripping edge | 7mm |
| Max. Die-cutting Pressure | 250T |
| Paper Processed | 200--2000 g/m2 |
| Cardboard Corrugated paper | up to 8mm |
| Die-cutting precision | ±0.25mm |
| Max. Die-cutting Speed | 5000sheets/h |
| Max. Height of Feeding Pile | 1500mm |
| Max. Height of Delivery Pile | 1250mm |
| Power of main motor | 11KW |
| Total Power | 18KW |
| Weight | 15T |
| Dimensions | 5700×2300×2200mm |
Description :
YH-1300 Automatic Die Cutting and Creasing Machines are key equipments applying to die-cutting, creasing, and cold embossing for cartons, paper boxes and paper labels, etc. High-precision intermittent mechanism, pneumatic chase locking mechanism, air clutch, overload protector and special driving device, registration mechanism ensure smooth feeding, accurate registering and order delivery.
Computer control and man-machine interface are adopted to display working state and solution for accident occurs automatically.
Imported control mechanism and key parts with fine assembly ensure stable pressure accuracy registration and safety.
