| Place of Origin: | China |
|---|---|
| Brand Name: | PRINTYOUNG |
| Certification: | CE |
| Model Number: | PRY-691S |
| Minimum Order Quantity: | 1 Set |
| Price: | US 13000 Set |
| Packaging Details: | Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included. |
| Delivery Time: | 30 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 30 Set/Sets per Month |
| Type: | Inkjet Printer | Print Dimension: | 210 Mm |
|---|---|---|---|
| Plate Type: | Flatbed Printer | Usage: | Paper Printer |
| Automatic Grade: | Automatic | Color & Page: | Multicolor |
| Voltage: | 220 V | Dimensions: | 1,315 * 788 * 776 Mm |
| Weight: | 195 KG | Ink Type: | UV Ink |
| Key Selling Points: | Automatic | Printing Method: | Hp Pagewide Bubble-Jet Print Technology |
| Print Head: | 1/2pcs * HP Pagewide Print Head | Print Head Protection Technology: | Carriage Anti-scratch Kit |
| Print Speed: | 10~40meter/min | RIP Software: | Control &Rip All In One |
| Control Interface: | Touch Screen Go With PLC | Connectivity: | Ethernet Cable |
| Power Requirements: | 20A Single-phase 220 V, 50HZ | Acoustic Noise Level: | 75 DB (A) Or Less |
| High Light: | Automatic Box Printer Machine 210mm,UV Ink Box Printer Machine,Box Printing Machine 40meter/Min |
||
|
Printing Method
|
Hp Pagewide Bubble-Jet Print Technology
|
|
|
Print Head
|
1/2pcs * HP Pagewide Print Head
|
|
|
Print Nozzle Ammount
|
42240 Nozzles per each head,
(4224 nozzles Per each Row. 10 Row per each head)
|
|
|
Print Resolution(Dots Per Inch)
|
1200*300dpi,1200*400dpi,
1200*600dpi,1200*1200dpi
|
|
|
Print Head Protection Technology
|
Carriage anti-scratch kit
|
|
|
Print Speed
|
10~40meter/min
|
|
|
RIP Software
|
Control &Rip all in one
|
|
|
Control Interface
|
Touch screen go with PLC
|
|
|
Media Type
|
Corrugated paper,Pizza boxs,Shopping bags,
Coffee bags,Paper cups,Envelope,Cards,Napkins, Tissue, ...
|
|
|
Media Margin Aligment
|
Laser Aligment
|
4~6pcs Automatic Laser guideline margin
|
|
Media Height Control
|
Electronic
|
Touch screen control electronic up down motion
|
|
Media
|
Maximum Printing Area
|
1Head: 8.26"(Width)*Y no limited In.
(210mm*Y no limited)
|
|
2Heads: 16.53"(Width)*Y no limited In.
(420mm*Y no limited)
|
||
|
Maximum Load Size
|
Without side flank: 23.6" (width) × Y no limited in.
(600mm * Y no limited)
|
|
|
With side flank: 47.2" (width) × Y no limited in.
(1200mm * Y no limited)
|
||
|
Maximum Thickness
|
9.84" in. (250 mm)
|
|
|
Auto Media Sender
|
Electronic Automatic Media Sender
|
Aavaliable,Automatic card and paper release sender,
Optional purchase
|
|
Ink
|
Type
|
Aqueous,Dye,Pigment
|
|
Color
|
Black,Cyan,Magenta,Yellow
|
|
|
Ink Tank Capacity
|
500ml per each color
|
|
|
Media Vacuum System
|
Vacuum Power
|
420W,Optional purchase
|
|
Vacuum Control
|
Touch screen control
|
|
|
Dimensions
|
Machine Size
|
51.7 (L) × 31.0 (W) × 30.6 (H) in.
(1,315 × 788 × 776 mm) Main printer
|
|
Packing Size
|
63.8 (L) × 34.9 (W) × 39.0 (H) in.
(1,620 × 887× 990 mm) Main printer
|
|
|
Weight
|
Net Weight
|
429 lb (195kg) Main printer
|
|
Gross Weight
|
605 lb (275 kg) Main printer
|
|
|
Environment
|
Temperature
|
59 to 86 °F (15 to 30 °C)
|
|
Humidity
|
40 to 80 %
|
|
|
Included Items
|
Print cable,cleaning kit,
USB Flash of manuals and installation videos
|
|
|
Connectivity
|
Ethernet cable
|
|
|
Power Requirements
|
20A Single-phase 220 V, 50HZ
|
|
|
Acoustic Noise Level
|
75 dB (A) or less
|
|
