Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping

Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping
Basic Information
Place of Origin: China
Brand Name: PRINTYOUNG
Certification: CE
Model Number: AEM1080Q
Minimum Order Quantity: 1 Set
Price: US 100000 Set
Packaging Details: Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Delivery Time: 45 days
Payment Terms: L/C, T/T
Supply Ability: 20 Set/Sets per Month
Contact Now
Type: Die-cutting Machine Voltage: 380V
Dimension: 5880(+1650) *2100(+1600) * 2350 Mm Weight: 16 T
Warranty: 1 Year Production Capacity: 7000 S/H
Key Selling Points: High Precision Max. Workable Width: 1080 * 780 Mm
Core Components: Motor, Pump, Engine, PLC PLC Brand: FATEK
Max Cutting Size: 1075 X 770 Mm Die Frame Inner Size: 1100 X 790 Mm
Cutting Plate Size: 1080 X 780 Mm Min Gripper Needle Size: 7 Mm
Cutting Precision: ≤±0.1 Mm Max Cutting Pressure: 300 T
Max Cutting Speed: 7000 S/H Pre-stacking Height: 1550 Mm
Delivery Stack Height: 1400 Mm
Highlight:

Automatic Paper Sheet Cutting Machine 380V

,

Waste Stripping Industrial Die Cutting Machine

,

Automatic Die Cutting And Creasing Machine

Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 0
                                      Pry-AEM1080Q Fully Automatic Paper Die Cutting Machine
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 1

Features

Complete design, accurate installation, high stability, high security, low noise.
★ Adopt worm, worm gear, crankshaft transmission, high cutting pressure, high durability.
★ High precision interval mechanism, high cutting precision, running steadily.
★ Adopt European feeder, suction adjustable, steadily, precise, good paper applicability.
★ Non-stop feeding, pre-stacking and delivery device can shorten the auxiliary time, improve the efficiency.
★ Automatic pressure adjust system, pressure digital display.
★ Human-friendly designed die frame and baseplate, makes installation, adjustment convenient.
★ Pneumatic die locking device, die frame fixed more steadily, accurately, time saving.
★ Front lay, side lay, feeding device fine tuning device, paper positioning more accurate,
★ Double, crooked, empty optoelectronic position control, ensure the paper in the right position, reduce waste.
★ Electronic control module design, adopt imported electronic components, ensure the accuracy and reliability.
★ Touch screen man-machine interface, real-time monitor the running situation, makes machine adjustment, troubleshooting more convenient.
★ Cycling cooling oil supply system ensure the movement parts get adequately lubricated to ensure the durability.
★ Adopt fixed quantity at fixed timing oil supply system, ensure the movement parts get adequately lubricated to let better durability.
★ 5+2mm thin plate system, reduce the make-ready time.
Technical Parameters
Pry-AEM1080Q fully automatic paper die cutting machine
Model No.
Pry-AEM1080Q
Max paper size:
1080 x 780 mm
Min paper size:
400 x 330 mm
Max cutting size:
1075 x 770 mm
Die frame inner size:
1100 x 790 mm
Cutting plate size:
1080 x 780 mm
Min gripper needle size:
7mm
Cutting precision:
≤±0.1 mm
Max cutting pressure:
300 T
Max cutting speed:
7000 S/H
Prestacking height:
1550 mm
Delivery stack height:
1400 mm
Application:
White board:
0.1～2 mm
Corrugated paper:
＜4 mm
Main motor power:
11 KW
Total power:
17.8 KW
Dimension: 【L(+ prestacking)x W(+ platform)x H】
AEM1080:
4880(+1650) x 2100(+1600) x 2350 mm
AEM1080Q:
5880(+1650) x 2100(+1600) x 2350 mm
weight
AEM1080
14 T
AEM1080Q
16 T
Configuration
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 2 Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 3
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 4 Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 5
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 6

Samples

Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 7
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 8
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 9
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 10
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 11
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 12
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 13
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 14
Pry - AEM1080Q Fully Automatic Paper Die Cutting Machine With Waste Stripping 15

Q1: Are you a manufacturer or a trading company?

A: Our shanghai office is mainly doing export. We have our own factory in Wenzhou, Zhejiang Province.

Q2. What is the machine warranty?

A: One year. After the warranty, we still provide technical support to buyer at low cost.

Q3. What is the production time while placing order?

A: Normally about 10-20 days.

Q4. What is the delivery time?

A: 15-30days after deposit.

Q5. Can your company handle shipping for customers?

A: Yes, just give us destination sea port or container yard.

Q6. Does the packing strong?

A: Yes. Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included..

Q7. How about the machine installation and training ?

A: 1)We provide training in our factory for free;
2)We can send technicians (engineers) to your factory for installation and training. You shall pay the round trip air fare and accommodations, plus each technician charges USD100/per day.

Q8. Do you have machines in stock?

A: For standard model, we have a large quantity in stock. For special model, we need 20-30 days to produce it for you.

Q9. How can you assure the machines’ quality?

A: Each machine will be test running at least 24 hours before delivery to assure the quality. And during the warranty, we will give spare parts for free if machine has any problem.

Q10. Do you inspect machines or test running before packing?

A: Of course we do. We have QC department to debug the machine before packing. If you want to use specific material to do the test running, you need to pay for the cost of the material

Q11. What’s the payment term?

A: T/T 50% in advance, the balance shall be paid before delivery. We also accept payment by West Union or L/C at sight.

Q12. Do you accept factory visiting?

A: Warmly welcome for your visiting.

Q13. How many years are you in printing field?

A: Shanghai company is 12 years old, the factory is more than 20years.

Q14. How many clients do you have?

A: We have sold our machines to about 60 countries. We have agents in South Africa, Morocco and Italy.
