Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800

Basic Information
Place of Origin: China
Brand Name: PRINTYOUNG
Certification: CE
Model Number: AS-800
Minimum Order Quantity: 1 Set
Price: US 42500 Set
Packaging Details: Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Delivery Time: 45 days
Payment Terms: L/C, T/T
Supply Ability: 5 Set/Sets per Month
Model: AS-800 Paper Material: Cardboard 210-800gsm,E/N/F Flute
Max. Speed: 300m/min Max .thickness Of Folded Box: 12mm
Way Of Folding: Fold 1 And Fold 3 Are 180°and 135°,fold 2 And Fold 4 Are 180° Power Supply: 3P 380V 50HZ
Blank Width: 800mm Length X Width X Height: 12x1.23x1.4m
Net Weight: 4.5T Total Power: 12.7kw
High Light:

Four Fold Folder Gluer Machine

,

Bottom Lock Folder Gluer Machine

,

Automatic Folder Gluer 300m/Min

Products Description
AS-800 Automatic Bottom Lock Folder Gluer Machine
Technical Parameters
SW-820 Film Laminator Machine
Model
800
Paper material
Cardboard 210-800gsm,E/N/F Flute
Max. speed
300m/min
Max .thickness of folded box
12mm
Way of folding
Fold 1 and fold 3 are 180°and 135°,fold 2 and fold 4 are 180°
Power supply
3P 380V 50HZ
Blank width
800mm
Length x Width x Height
12x1.23x1.4m
Net Weight
4.5T
Total power
12.7kw
Configuration
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 0

1.Paper Feeding Section

6pcs Adjustable feeding belts to ensure easy adjustment,stable and smoothly feeding. Continuously variable Speeder to ensure feeding internal and stable transmission.
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 1

2.Aligner Section

Equipped with autocorrection device to correct the obliquity and ensure the correct feeding.
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 2

3.Pre-folding Section

Double-board structure with a set of prefolding knife .Pre-fold angle is 180°and 135°,especially suitable for small but high cartons,more satisfactory while rapid prototyping.
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 3

4.Lock Bottom Section

3-board tracking structure,upper glue can make bottom-locked box automatic gluing and forming.The entire bottom-lock part is installed in a reversible bracket,substantially reduce the swap adjustment time of bottom-fold box and the other types of box.
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 4

5.Lower Gluing Tank

Equipped with the lower gluing tank.
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 5

6.Folding and Closing

The folding is equipped with the driving belt,folding belts have corrective function,
extension work,make the box forming more stable.
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 6

7.Trombone Section

Adjust the pressure easily and reliably to ensure the gluing quality;Equipped with pneumatic counting device which makes the counting conveniently.The press is equipped with independent speeder.The operator can set the collecting speed.
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 7

8.Transmission

Press:Equipped with one-touch pneumatic pressure adjustment,easy operation.Press has two functions:
1.waiting,when feeding is paused,press will auto enter into waiting state.
2.Travel switch,pause the machine in cas.

Samples Parameters

The following are the main parameters of straight line box and crash lock bottom box.
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 8
Straight Line Box
Model
800Type
Way of folding
Two carriers
B+C+D+E
130-800
C+D(Min)
65
F
70-700
G(Max)
700
D+E(Max)
300
G(Max)
400
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 9
Crash Lock Bottom Box
Model
800Type
Way of folding
Two carriers
B+C+D+E
130-800
C+D(Min)
65
F
70-700
G(Max)
700
H(Min)
25
L(Max)
30-100

Application

Widely used in all kinds of packaging boxes in life.
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 10
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 11
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 12
Customer
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 13
Company Profile
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 14
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 15
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 16
Why Choose Us
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 17
Product packaging
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 18
Four Fold Bottom Lock Automatic Folder Gluer 300m/Min AS-800 19
FAQ
Q1: Are you a manufacturer or a trading company?
A: Our shanghai office is mainly doing export. We have our own factory in Wenzhou, Zhejiang Province.

Q2. What is the machine warranty?
A: One year. After the warranty, we still provide technical support to buyer at low cost.

Q3. What is the production time while placing order?
A: Normally about 10-20 days.

Q4. What is the delivery time?
A: 15-30days after deposit.

Q5. Can your company handle shipping for customers?
A: Yes, just give us destination sea port or container yard.

Q6. Does the packing strong?
A: Yes. Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included..

Q7. How about the machine installation and training ?
A: 1)We provide training in our factory for free
2)We can send technicians (engineers) to your factory for installation and training. You shall pay the round trip air fare and accommodations, plus each technician charges USD100/per day.

Q8. Do you have machines in stock?
A: For standard model, we have a large quantity in stock. For special model, we need 20-30 days to produce it for you.

Q9. How can you assure the machines’ quality?
A: Each machine will be test running at least 24 hours before delivery to assure the quality. And during the warranty, we will
give spare parts for free if machine has any problem.

Q10. Do you inspect machines or test running before packing?
A: Of course we do. We have QC department to debug the machine before packing. If you want to use specific material to do the test running, you need to pay for the cost of the material.

Q11. What’s the payment term?
A: T/T 30% in advance, the balance shall be paid before delivery. We also accept payment by West Union or L/C at sight.

Q12. Do you accept factory visiting?
A: Warmly welcome for your visiting.

Q13. How many years are you in printing field?
A: Shanghai company is 12 years old, the factory is more than 20years.

Q14. How many clients do you have?
A: We have sold our machines to about 60 countries. We have agents in South Africa, Morocco and Italy.
