| Place of Origin: | China |
|---|---|
| Brand Name: | PRINTYOUNG |
| Certification: | CE |
| Model Number: | AEMG-1080T |
| Minimum Order Quantity: | 1 Set |
| Packaging Details: | Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included. |
| Delivery Time: | 45 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10 Set/Sets per Year |
| Max Sheet Size: | 1080 X 780 Mm | Min Sheet Size: | 400 X 300 Mm |
|---|---|---|---|
| Max Die Cutting Area: | 1075 X 770 Mm | Die Chase Inner Size: | 1100 X 790 Mm |
| Cutting Plate Size: | 1080 X 780 Mm | Max Stamping Area: | 1060 X 760 Mm |
| Min Gripper Margin: | 7 Mm | Cutting Precision: | ≤±0.1 Mm |
| Stamping Precision: | ≤±0.1 Mm | Holographic Sensor Precision: | ≤±0.05 Mm |
| Max Cutting Speed: | 7000 S/H | Max Bronzing Speed: | 6500 S/H |
| Foil Roll Max Diameter: | Φ250 Mm | Vertical Foil Width: | 15~1060 Mm |
| Horizon Foil Width: | 15~760 Mm | Vertical Foil Axle: | 3 Pcs |
| Vertical Holographic Sensor: | 3 Pcs | Horizon Foil Axle: | 2 Pcs |
| Heating Area: | 12 Pcs | Temperature Range: | 50~199 ℃ |
| Pre-stacking Height: | 1550 Mm | Delivery Stack Height: | 1500 Mm |
| Cardboard: | 0.1～2 Mm | Corrugated Paper: | ＜4 Mm |
| Main Motor Power: | 11 KW | Heating Area Power: | 24 KW |
| Total Power: | 60 KW | Dimension: | 5600(+1600)x2550(+1400)x2600 Mm |
| Weight: | 18 T | ||
| Highlight: | 11KW Paper Sheet Cutting Machine,Paper Sheet Cutting Machine 7000S/H,7mm Gripper Paper Sheet Cutting Machine |
||
