|Place of Origin:
|Minimum Order Quantity:
|L/C, D/A, D/P, T/T, Western Union, MoneyGram
|30 sets per month
|Paper Wrap Thickness:
Rigid Jewelry Gift Box Making Machine,
Automatic Jewelry Gift Box Making Machine,
30 Sheets/Min Gift Box Making Machine
PRY-S420Y Automatic Rigid Box Making Machine
This machine is mainly used for producing boutique boxes with high requirements,like high grade boxes for iPhone, iPad,Jewelry gift, makeup,etc. It can work with Rigid Box Molding&Folding Machine according to requirement of the boxes.
1. Adopts paper feeding principle same with automatic rigid box maker, with stable performance.
2. Adopts YAMAHA robot, can automatically fetch the rough box to the required position accurately.
3. Adopts visual positioning system,the positioning accuracy is≤±0.1mm.
Paper wrap size
A min 100mm
A max 460mm
B min 190mm
B max 830mm
Paper wrap thickness
Finished box size
Max 320 Min 100
Max 240 Min 50
Max 125 Min 15
Remark:For the specific parameters of the selected models in Zone A/B, please refer to the stand-alone parameter list.
1.Feeder servo automatic paper feeding.(Can freely adjust each functional bit parameter according to product characteristics to adapt to more product types)
2.Self-centering function of paper pile.(Motor drive eliminates the error caused by manual adjustment of the paper stopper)
3.Standard glue viscosity controller(Avoid product quality problems caused by glue viscosity and reduce the difficulty of operation)
4.High strength monochrome PU conveyor belt(Compared with rubber belts, it can achieve smaller deformation and easier to wipe. It can be replaced with black and white dual-color belts according to customer needs)
5.Rear Drive Servo Drive(Achieve more stable belt operation and longer service life)
6.Equipped with waste collection roller(The back end of the equipment is equipped with a waste collection roller to provide convenience for customer
7.Absolute carton positioning device(The double-cylinder positioning carton ensures that each carton is in a uniform position, which has incomparable advantages compared to the structure that needs to be positioned by the relative friction between the carton and the belt.)
8.Japan YAMAHA manipulator and dual 500W industrial cameras(Compared with a single camera with a large field of view, the positioning accuracy is more accurate, and the high-power SCARA achieves faster speed and accuracy)
9.Camera electric adjustment device(Equipped with roller screws to achieve more accurate camera position adjustment, with self-locking function to place the camera moving due to equipment movement)
10.Automatic holding box device(Raise the paper box and facial paper by 15mm to reduce product loss caused by friction between the facial paper and the conveyor belt)
11.Blocking alarm device(Automatic discharge and feed detection to avoid damage to accessories due to material blocking)
12.Blocking alarm device(Automatic discharge and feed detection to avoid damage to accessories due to material blocking)
