Automatic PLC Control Case Making Machine 25pcs/Min Speed

Basic Information
Place of Origin: China
Brand Name: PRINTYOUNG
Certification: CE
Model Number: QFM-600
Minimum Order Quantity: 1 Set/Sets
Price: USD53000.00-USD60000.00 per/set
Packaging Details: wooden case
Delivery Time: 60days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 25sets/month
Length Of Paper: 230-1030mm Width Of Paper: 100-600mm
Thickness Of Paper: 80~200g/m2 Thickness Of Cardboard: 1-3mm
Min Width Of Spine: 8mm Speed: 0-25pcs/min
Power: 12.5kw Weight: 2800kg
Dimension: L9400×W2600×H1500mm
High Light:

12.5kw automatic case making machine

,

PLC control book case making machine

,

25pcs/min case making machine

QFM-600 Automatic High Accuracy Stable 80~200g/M2 Case Making Machine

QFM-600 Automatic High Accuracy Stable Case Making Machine

Introduction:

QFM-460/600 New Automatic Lining machine used to make lining for perfect book covers, cover of notebook, calendars, hanging calends, cover of box ,file etc.

Features:

1.It adopts high speed automatic paper feeding system,which is controlled pneumatically, and its structures simple and reasonable.

2.New designed copper scraper cooperates with the rubber more compactly, efectively avoiding paper winding.
And the copper scraper is more durable

3.New designed copper scraper cooperates with the rubber more compactly, efectively avoiding paper winding.
And the copper scraper is more durable

4.Paper feeding and positioning system adopt imported highprecise photoelectric control device to make the paper and cardboard location more accurate.

5.It adopts PLC control, featuring in simple operation. The troubles are displayed directly on the HMI, which helps the operator easily remove them

Main Technical parameter

Model QFM-460 QFM-600
Length of paper 190-830mm 230-1030mm
Width of paper 100-460mm 100-600mm
Thickness of paper 80~200g/m2 80~200g/m2
Thickness of cardboard 1-3mm 1-3mm
Min width of spine 8mm 8mm
Speed 0-25pcs/min 0-25pcs/min
Power 11.5kw 12.5kw
Weight 2500kg 2800kg
Dimension L7500×W2000×H1500mm L9400×W2600×H1500mm



Product sample drawing

Automatic PLC Control Case Making Machine 25pcs/Min Speed 0



Combined craft flow line



Automatic PLC Control Case Making Machine 25pcs/Min Speed 1



Automatic PLC Control Case Making Machine 25pcs/Min Speed 2Automatic PLC Control Case Making Machine 25pcs/Min Speed 3
