400kg Hydraulic Guillotine Cutting Machine FN-H520T V7

Basic Information
Place of Origin: China
Certification: CE
Model Number: FN-H520T V7
Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: wooden case each paper Cutting Machine
Delivery Time: within 40 days
Payment Terms: L/C, T/T
Supply Ability: 30sets per month
Model: FN-H520T V7 Cutting Width: 520mm/20.47"
Cutting Height: 80mm/3.15" Min. Cutting: 30mm/1.18"
Cutting Depth: 520mm/20.47" Cut Precision: ≤0.2mm
Machine Dimension: 1280*1010*1430mm Net Weight: 400kg
High Light:

hydraulic guillotine cutting machine


400kg guillotine cutting machine


SGS Guillotine Paper Cutting Machine

FN-H520T V7 400kg Hydraulic Guillotine Toilet Paper Roll Cutting Machine

FN-H490T V7 Hydraulic Min. cutting Guillotine Paper Roll Cutting machine



1. Cutting & pressing mode are hydraulic, with Taiwan imported motor;
2. Infrared for safety operation with CE by SGS;
3. 100groups x 96 steps program for repeat cuts
4. Single clamping button for convenient operation.
5. Top-suspended ball screw and nut for pushing paper.
6. Electronic hand wheel for backgauge position with variable speed.
7. Cutting motor with non-noise.
8. 7" touch screen, intelligent control;


Technical Parameters
FN-H520T V7 400kg Hydraulic Guillotine toilet paper roll Cutting machine
Model Cutting width Cutting height Min. cutting Cutting depth Cut precision Machine Dimension Net Weight
FN-H490T V7 490mm/19.29" 80mm/3.15" 30mm/1.18" 490mm/19.29" 0.2mm 1280*980*1430mm 360kg
FN-H520T V7 520mm/20.47" 80mm/3.15" 30mm/1.18" 520mm/20.47" 0.2mm 1280*1010*1430mm 400kg
FN-H670T V7 670mm/26.38" 80mm/3.15" 30mm/1.18" 670mm/26.38" 0.2mm 1400*1150*1460mm 450kg



400kg Hydraulic Guillotine Cutting Machine FN-H520T V7 0400kg Hydraulic Guillotine Cutting Machine FN-H520T V7 1400kg Hydraulic Guillotine Cutting Machine FN-H520T V7 2


400kg Hydraulic Guillotine Cutting Machine FN-H520T V7 3400kg Hydraulic Guillotine Cutting Machine FN-H520T V7 4400kg Hydraulic Guillotine Cutting Machine FN-H520T V7 5400kg Hydraulic Guillotine Cutting Machine FN-H520T V7 6400kg Hydraulic Guillotine Cutting Machine FN-H520T V7 7



Q1: Are you a manufacturer or a trading company?

A: Our shanghai office is mainly doing export. We have our own factory in Wenzhou, Zhejiang Province.

Q2. What is the machine warranty?

A: One year. After the warranty, we still provide technical support to buyer at low cost.

Q3. What is the production time while placing order?

A: Normally about 10-20 days.

Q4. What is the delivery time?

A: 15-30days after deposit.

Q5. Can your company handle shipping for customers?

A: Yes, just give us destination sea port or container yard.

Q6. Does the packing strong?

A: Yes. Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.

Q7. How about the machine installation and training ?

A: 1)We provide training in our factory for free; 2)We can send technicians (engineers) to your factory for installation and training. You shall pay the round trip air fare and accommodations, plus each technician charges USD100/per day.

Q8. Do you have machines in stock?

A: For standard model, we have a large quantity in stock. For special model, we need 20-30 days to produce it for you.

Q9. How can you assure the machines’ quality?

A: Each machine will be test running at least 24 hours before delivery to assure the quality. And during the warranty, we will give spare parts for free if machine has any problem.

Q10. Do you inspect machines or test running before packing?

A: Of course we do. We have QC department to debug the machine before packing. If you want to use specific material to do the test running, you need to pay for the cost of the material

Q11. What’s the payment term?

A: T/T 30% in advance, the balance shall be paid before delivery. We also accept payment by West Union or L/C at sight.

Q12. Do you accept factory visiting?

A: Warmly welcome for your visiting.

Q13. How many years are you in printing field?

A: Shanghai company is 12 years old, the factory is more than 20years.

Q14. How many clients do you have?

A: We have sold our machines to about 60 countries. We have agents in South Africa, Morocco and Italy.
