ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine

ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine
ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine
ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine
Basic Information
Place of Origin: China
Brand Name: PRINTYOUNG
Certification: CE
Model Number: ZH-800G
Minimum Order Quantity: 1 Set/Sets
Price: Discussible
Packaging Details: wooden case
Delivery Time: 2 Weeks
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 Units per year
Contact Now
Voltage: 380V,4.5KW Condition: New
Driven Type: Electric Type: Gluing Machine
Certification: CE Certificate Warranty: 1 Year
Weight: 1.9t Dimension: 10.2*1.5*1.3M
Steel Frame Packing Size: 12.32m³1888/2185kg Conveyor Part: 3660*950*1110=3.86 M³ 475/587kg
Highlight:

4.5KW Box Folding Machine

,

Cold Glue Box Folding Machine

ZH-800G Full-Automatic Bottled Olive Oil Box Folding Gluing Machine



Feature:

ZH-800G is our most competitive folder gluer with crash lock bottom which developed by ourselves. It has two National Patents. Its easy operation, reasonable price and wide application make it a new leap forward in the history of folder gluer. It combines a variety of folder gluer functions: straight line box, pre-fold box, crash lock bottom box. Our machine is featured by multi-function, wide application, easy operation and competitive price. Compared to older generation folder gluer, our machines simplify the complicated construction, reduce the difficulty of test run and reduce the cost. Especially for the current packaging and printing industry with tough competition, it can help to shorter delivery time and recover your invest easily. It is ideal equipment in printing industry.



  1. Line speed: 0—220m/min adjustable
  2. Usage paper: 210-660g/m²paperboard
  3. Box forming:Either side folds, either sides pre-fold, and crash lock bottom
  4. Paperboard Feeding: Continuous automatic
  5. Way of folding: First, second and fourth lines fold 180 degree, third line fold 135 degree.
  6. Glue Type: Cold glue
  7. Power: three-phase, AC380V, (600G)3.2kw (700G)3.2kw (800G)4.5kw
  8. Weight: 1600kg,1800kg,2000kg
  9. Dimension: (600G)8500×1200×1300mm (700G)8500*1350*1300mm (800G)10000*1500*1300mm
  10. The counting range: 0～999999(full-automatic)

Technical Parameters



Line Speed 0-220m/min continuous adjustment
Suitable paper 210-600g/m² paperboard
Box Forming single side gluing or both side gluing and pre-folding , crash lock bottom
delivery Paper feeding
Glue Cold glue
Power 380V 4.5KW
Weight 1.9t
Dimension

10.2*1.5*1.3M
Steel frame Packing Size

12.32m³1888/2185kg
Feeding Part

2700*1150*1235=3.83m³ 783/886kg
Folding Part

2885*1300*1235=4.63m³ 630/712kg
Conveyor Part

3660*950*1110=3.86 m³ 475/587kg

Box specification

ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine 0

Box Type
A
B
C(min)
D(min)
Side-Glue Box(I)
130-800
60-700
60
10
Pre-Folding Box(I)
170-800
60-700
80
10
Crash Lock Bottom Box(II)
180-760
100-700
90
50

ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine 1



Product display

ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine 2



Company Profile

ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine 3ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine 4ZH-800G Paper Feeding Cold Glue Olive Oil 4.5KW Box Folding Machine 5
FAQ

Q1: Are you a manufacturer or a trading company?

A: Our shanghai office is mainly doing export. We have our own factory in Wenzhou, Zhejiang Province.

Q2. What is the machine warranty?

A: One year. After the warranty, we still provide technical support to buyer at low cost.

Q3. What is the production time while placing order?

A: Normally about 10-20 days.

Q4. What is the delivery time?

A: 15-30days after deposit.

Q5. Can your company handle shipping for customers?

A: Yes, just give us destination sea port or container yard.

Q6. Does the packing strong?

A: Yes. Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.

Q7. How about the machine installation and training ?

A: 1)We provide training in our factory for free; 2)We can send technicians (engineers) to your factory for installation and training. You shall pay the round trip air fare and accommodations, plus each technician charges USD100/per day.

Q8. Do you have machines in stock?

A: For standard model, we have a large quantity in stock. For special model, we need 20-30 days to produce it for you.

Q9. How can you assure the machines’ quality?

A: Each machine will be test running at least 24 hours before delivery to assure the quality. And during the warranty, we will give spare parts for free if machine has any problem.

Q10. Do you inspect machines or test running before packing?

A: Of course we do. We have QC department to debug the machine before packing. If you want to use specific material to do the test running, you need to pay for the cost of the material

Q11. What’s the payment term?

A: T/T 30% in advance, the balance shall be paid before delivery. We also accept payment by West Union or L/C at sight.

Q12. Do you accept factory visiting?

A: Warmly welcome for your visiting.

Q13. How many years are you in printing field?

A: Shanghai company is 12 years old, the factory is more than 20years.

Q14. How many clients do you have?

A: We have sold our machines to about 60 countries. We have agents in South Africa, Morocco and Italy.
