PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine

PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine
Basic Information
Certification: CE
Model Number: PRY-900
Minimum Order Quantity: 1 Set
Price: US 13000 Set
Packaging Details: Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Delivery Time: 45 days
Payment Terms: L/C, T/T
Supply Ability: 30 Set/Sets per Month
Contact Now
Place Of Origin: Zhejiang, China Brand Name: PRINTYOUNG
Type: Slitting Rewinder Applicable Industries: Manufacturing Plant
Showroom Location: Egypt, Italy, Algeria, South Africa, Morocco Warranty: 1 Year
Key Selling Points: High-accuracy Machinery Test Report: Provided
Video Outgoing-inspection: Provided Condition: New
Computerized: Yes Voltage: 220V
Dimension: 1900*1950*1700mm Max. Unwinding Width: 900mm
Max. Unwinding Dia: 1000mm Max. Rewinding Dia: 270mm
Min Slitting Width: 30mm Machine Max. Speed: 110m/min
Main Power: 2.95kw Unwinding Shaft: 3'' (76mm) Air Eapanding Shaft
Rewinding Shaft: 0.5'', 1'' Or As Your Request Weigth: 1200kg
High Light:

Thermal Paper Slitting And Rewinding Machine

,

Automatic Paper Slitting And Rewinding Machine

,

Automatic Paper Slitter Rewinder Machine

PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 0
PRY-900 Thermal Paper Slitting Rewinding Machine
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 1
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 2
Technical Parameters
PRY-900 Thermal Paper Slitting Rewinding Machine
Max. Unwinding Width
900mm
Max. Unwinding Dia
1000mm
Max. Rewinding Dia
270mm
Min Slitting Width
30mm
Machine Max. Speed
110m/min
Main Power
2.95kw
Unwinding Shaft
3’’ (76mm) air eapanding shaft
Rewinding Shaft
0.5’’, 1’’ or as your request
Weigth
1200kg
Demension
1900*1950*1700mm/2000mm
Configuration

Unwinding Section

-Chain link automatic lift-up loading system
-Constant tension implant in PLC
-3’’(76mm)air expanding shaft

Slitting Section

-Disc cutter
-Disc Cutter Assembly adopt the cam self-locking
-Cutter with adjustable and moveable blade base
-Meter counter

Rewinding Section

-0.5”,1”,1.5” or as your request
-Pressure roller
-Center Rewinding technology

Controlling Section

-Siemens PLC & HMI
-Low voltage electrical appliances all from Schneider
-All the parameters are displayed on the monitor

Trimmed Waste Edge

-Edge Waste Blower with Expulsion Tube

Optional

-Automatic Paper Core Loader
-Automatic Cutting & Gluing Device
-Automatic Roll Cut Off & Hammer Unit
-Whole Packing Line for Thermal Rolls
Optional 1:Automatic Cutting & Gluing Device(Payable)
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 3
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 4
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 5
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 6
Optional 2:Automatic Paper Core Loading Machine
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 7
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 8PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 9PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 10
Capacity
0.13/m3
Min.Pipe Dia
12mm
Max. Pipe Dia
25mm
Working Speed
15times/min
Power
0.7KW
Size
1000*1000*1200mm
Weight
350kgs
Option 3.Automatic Roll Cut Off & Hammer Unit
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 11
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 12PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 13
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 14PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 15PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 16
Temperature compensating solid state controllers.
Belt conveyor with variable speed and adjustable.
Top& side heat,stainless-steel heater.
Quick change seal wire with tension assembly.
Double Magnetic Hold-down; Sealing blade on top(L-sealer).
Roller,wire mesh optional.
High velocity turbo-tunnel.
Combination unit-system runs on one circuit.
Works with all types of shrink films,but specially tunnel for non-PVC,polyolefin films.
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 17PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 18
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 19
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 20
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 21
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 22
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 23
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 24
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 25
PRY-900 Automatic Thermal Paper Slitting And Rewinding Machine 26
Q1.Are you a manufacturer or a trading company?
A:Our shanghai office is mainly doing export.We have our own factory in Wenzhou,Zhejiang Province.
Q2.What is the machine warranty?
A:One year.After the warranty,we still provide technical support to buyer at low cost.
Q3.What is the production time while placing order?
A:Normally about 10-20 days.
Q4.What is the delivery time?
A:15-30days after deposit.
Q5.Can your company handle shipping for customers?
A:Yes,just give us destination sea port or container yard.
Q6.Does the packing strong?
A:Yes.Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions.A full set of maintenance and operation manuals is included.
Q7.How about the machine installation and training?
A:1)We provide training in our factory for free;2)We can send technicians (engineers) to your factory for installation and training.You shall pay the round trip air fare and accommodations,plus each technician charges USD100/per day.
Q8.Do you have machines in stock?
A:For standard model,we have a large quantity in stock.For special model,we need 20-30 days to produce it for you.
Q9.How can you assure the machines’ quality?
A:Each machine will be test running at least 24 hours before delivery to assure the quality.
And during the warranty,we will give spare parts for free if machine has any problem.
Q10.Do you inspect machines or test running before packing?
A:Of course we do.We have QC department to debug the machine before packing.
If you want to use specific material to do the test running,you need to pay for the cost of the material.
Q11.What’s the payment term?
A:T/T 30% in advance,the balance shall be paid before delivery.We also accept payment by West Union or L/C at sight.
Q12.Do you accept factory visiting?
A:Warmly welcome for your visiting.
Q13.How many years are you in printing field?
A:The Shanghai company since in 2008,the factory is more than 25years.
Q14.How many clients do you have?
A:We have sold our machines to about 60 countries.We have agents in South Africa,Morocco and Italy.
