7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine

7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine 7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine
Basic Information
Place of Origin: China
Brand Name: PRINTYOUNG
Certification: CE
Model Number: 760S
Minimum Order Quantity: 1 Set
Price: US 160,000 Set
Packaging Details: Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Delivery Time: 60 days
Payment Terms: L/C, T/T
Supply Ability: 1 Set/Sets per Month
Contact Now
Voltage: 380 V Power: 7.5 KW
Dimension: 5600*3840*1900 MM Weight: 4700 KG
Production Capacity: 1800 Decks/hour Max. Workable Width: 720*600 MM
Screw Air Compressor: 7.5kw 46#hydraulic Oil: 45 Liters
High Light:

380V Paper Processing Machinery

,

7.5kw Paper Processing Machinery

,

760S Automatic Cards Matching Machine

Products Description
                                        760S Automatic Cards Matching Machine
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine 0

Features

The fully automatic cards sorting machine developed by our company is mainly used for the slitting,stacking and die cutting of all kinds of card paper and playing card paper. It is not only efficient, but also has high slitting precision, which can be used for different specifications. It is the ideal equipment for professional manufacturing of cards and playing cards. The original electrical components of the machine adopt Schneider products imported from France, and the automatic whole-process assembly line is embodied as: automatic paper feeding, automatic vertical and horizontal slitting, automatic stacking, automatic card sorting, automatic counting detection, automatic boxing, and automatic plastic packaging. The equipment integrates light, electricity and gas, safe operation and stable performance.
Technical Parameters
760S Automatic Cards Matching Machine
Maximum paper size
720mm*600mm
Minimum paper size
500mm*380mm
Cards size
63mm*88mm/56mm*87mm
Paper thickness
280-350g
Running speed
1800 decks/hour
Paper typography
Playing cards typography
Machine weight
About 6 tons
46#hydraulic oil
45 liters
Screw air compressor
7.5kw one
Configuration
The automatic card slitting machine is divided into five parts according to the structure: paper feeding system, host part, round corner die cutting system, automatic counting system, automatic cigarette pack plastic sealing system

Paper feeding system

The main function of the paper feeder is to continuously feed a whole single sheet of paper to the main unit, mainly including:
1.Feeder head
The feeder head is an important part of the paper feeder, and its function is to separate the top sheet of the paper stack from the other sheets and transport it forward. The four-suction and four-delivery method is adopted to ensure that high-weight double-sided cardboard can be transported freely.
2.Double sheet controller
The function of the double-sheet controller is to guaranty that when the feeder feeds two or more papers forward at a time, it will automatically alarm and stop
3.Paper feeding roller
The pressure of each paper feed roller is adjusted to the same level to ensure the smooth delivery of paper.
4.Flap
When the paper delivery nozzle sucks the paper and starts to transport it forward, the flap starts to tilt forward. After the paper is sent to the pattern roller, the flap comes back and stands up.

Host part

1.Front gauge, side pull gauge
The paper is rectangular, and the side pull gauge distance are equal. Their function is to ensure that the paper and the pull gauge are at 90 degrees before the paper enters the slitting knife to locate the slitting precision.
2.Inclined roller/steel ball
Their function is to feed the paper to the second group of cutters after the paper passes through the slitting knife, and make the paper close to the gauge.
3.Support paper steelsheet
sheet Flatten the uneven paper so that the paper smoothly enters the pressure-feed synchronous belt.
4.Slitting knife stick
There are two sets of bottom knives and two sets of face knives. There are two types of face knives, light knives and flower knives, whose function is to divide the paper into rectangular semi-finished cards.
5.Pressure feeding synchronous belt
The function is to feed the slitted paper cards into the rubber rollers in turn.
6.Pull open the rubber roller
Adjust the pressure of the rubber rollers, and rely on the speed difference between the front and rear rubber rollers to break the paper carton with the connection point and send it to the paper delivery slot.

Fillet Die Cutting System

1.Die cutting channel
Through the sensor of the electric eye, the card in the delivery slot is sent into the die-cutting channel by the cylinder push rod to ensure the neat positioning of the cards before die-cutting
2.Paper cylinder
After the card enters the die-cutting channel, it starts to work by relying on the paper-aligning cylinder to align the cards.
3.Hydraulic cylinder
After the paper aligning cylinder work, the hydraulic cylinder starts to work and presses down the card in the channel vertically with a stroke of 15 cm.
4.Cutting Die
The function is to make the semi-finished products into card edges and rounded corners.

Point detection system

The function is to put the die-cut cards into the paper receiving slot individually in turn, and take pictures through the probe to detect and count the number of each card. If there is an error detected, it will automatically stop and remove the front and back of the problem 2- 3Play cards. Then restart the work, if the disordered card phenomenon is continuously detected, it will alarm and stop.

Automatic cigarette pack plastic sealing system

Through the wire-drawing packaging machine, the inspected cards are laminated with plastic film to wrap them into finished products.
Customer
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine 1
Company Profile
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine 2
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine 3
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine 4
Why Choose Us
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine 5
Product packaging
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine 6
7.5kw Paper Processing Machinery 760S Automatic Cards Matching Machine 7
FAQ
Q1: Are you a manufacturer or a trading company?
A: Our shanghai office is mainly doing export. We have our own factory in Wenzhou, Zhejiang Province.

Q2. What is the machine warranty?
A: One year. After the warranty, we still provide technical support to buyer at low cost.

Q3. What is the production time while placing order?
A: Normally about 10-20 days.

Q4. What is the delivery time?
A: 15-30days after deposit.

Q5. Can your company handle shipping for customers?
A: Yes, just give us destination sea port or container yard.

Q6. Does the packing strong?
A: Yes. Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions.
A full set of maintenance and operation manuals is included.

Q7. How about the machine installation and training ?
A: 1)We provide training in our factory for free
2)We can send technicians (engineers) to your factory for installation and training.
You shall pay the round trip air fare and accommodations, plus each technician charges USD100/per day.

Q8. Do you have machines in stock?
A: For standard model, we have a large quantity in stock.
For special model, we need 20-30 days to produce it for you.

Q9. How can you assure the machines’ quality?
A: Each machine will be test running at least 24 hours before delivery to assure the quality.
And during the warranty, we will give spare parts for free if machine has any problem.

Q10. Do you inspect machines or test running before packing?
A: Of course we do. We have QC department to debug the machine before packing.
If you want to use specific material to do the test running, you need to pay for the cost of the material.

Q11. What’s the payment term?
A: T/T 30% in advance, the balance shall be paid before delivery.
We also accept payment by West Union or L/C at sight.

Q12. Do you accept factory visiting?
A: Warmly welcome for your visiting.

Q13. How many years are you in printing field?
A: Shanghai company is 12 years old, the factory is more than 20years.

Q14. How many clients do you have?
A: We have sold our machines to about 60 countries. We have agents in South Africa, Morocco and Italy.
