High Speed 8 Colors 1000mm Flexo Printing Machine For Pe Activities

High Speed 8 Colors 1000mm Flexo Printing Machine For Pe Activities

    • High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities
    • High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities
    • High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities
    • High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities
    • High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities
  • High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities

    Product Details:

    Place of Origin: Shanghai
    Brand Name: Printyoung
    Certification: CE
    Model Number: YTB81000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: Daub rust-proof oil, then wrap stretch film, and then fixed inside the container
    Delivery Time: 5-10 days stock,20-60 days unstock
    Payment Terms: L/C, T/T, Western Union
    Contact Now
    Detailed Product Description
    Type: Flexographic Printer Plate Type: Resin Plate
    Usage: Paper Printer, Card Printer, Plastic Film Solidity: UV Curing
    Plate Material: Resin Or Rubber Blade: Doctor Blade
    Max Printing Width: 960mm Printing Length: 280-1000mm
    Printing Speed: 100m/min
    High Light:

    flexo printing press

    ,

    sticker printing machine

     8-Colors 1000mm High-Speed Flexo Printing Machine For Pe Activities



    Quick Detail



    This machine is suitable for printing such packing materials as polyethylene, polyethylene plastic bag glass paper and roll paper etc. And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.



    Specifications



    Model YTB-81000
    Material feeding width 1000mm
    Max Printing Width 960mm
    Colors 8 colors
    Material Non-woven fabric. Paper. Film. Aluminum foil. PVC.OPP.PE.BOPP.PE.NY.PET.CPP.
    Thickness of plate 1.7mm
    Printing length 280-1000mm
    Printing speed 100m/min
    Register precision ±0.03mm
    Machine dimension 5.3*2.3*3.94mm
    Power of machine 52KW


























    Suitable Material

    Kraft paper:40-350g/㎡ single-sided coated paper:30-350g/㎡ copy paper:15-350g/㎡ firecrackers and paper:40-350g/㎡ paper money and incense:25-350g/㎡ silicone paper:50-350g/㎡ coated paper:30-350g/㎡ dust-free paper:25-350g/㎡Release paper:40-350g/㎡ composite paper:30-350g/㎡













    Features

    Feeding material part:

    1. Single unwinder system, pneumatic loader for unwind system

    2. Automatic stop machine when break the material; When machine stop, keep tension and avoid the material loose or line deflection.

    3. Air shaft

    4. EPC (edge position control): With manually/automatically/ central return function, can adjust the rewind move left and right .

    5. Automatic tension control system with magnetic brake(5KG).

    6. Roller core diameter: 76mm

    7.Discharge maximum diameter: 1000mm



    Printing sections:

    1. plate roller circumference: 300-1000mm, standard less than 400mm

    2. print material: resin plate or rubber plate

    3. Transmission between printing roller and anilox roller: Helical gears

    4. printing chromatography: 360-degree rotation

    5. adjustment method: By Manual (Automatic printing after adjust by manual, when start machine, no need register color again, the printing pressure and register all keep the same.)

    6. Printing roller lifting system: Automatic Hydraulic cylinder control roll up and down.



    Drying system:

    1. The machine is equipped with blower and heater; and the heater employed central temperature control system

    2. Dry apparatus between each color, and one more dry apparatus after printing finished



    Rewinding Part:

    1. Single rewinder system, pneumatic loader for rewind system

    2. Film central rewind system

    3. Air shaft

    4. Roller core diameter: 76mm

    5. Discharge maximum diameter: 1000mm



    Competitive Advantage

    Reasonable structure, advanced technology, easy operation, stable performance, accurate color register.

    Adopting high-quality motor, high-quality inverter, save the electricity, reduce the run fluctuation.

    When the machine is stopped working, printing rolls still keep moving; when rise the printing roller ,ink motor running automatically ;when fallen the printing roller, ink motor stop running automatically.

    The machine is equipped with blower and heater; and the heater employed central temperature control system.



    Details Of Image

    High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities 0



    Plate roller

    standard 400mm for machine , making

    plate range 191--1000mm



    High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities 1

    Rubber Roller

    Transport the ink to Anilox roller



     High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities 2

    Doctor Blade

    Not spill the ink

    Equipped with ink pump, even the ink.Also have enclosed doctor blade



    High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities 3

    Ink pump

    Suck the ink automatically

    Adopt the automatic circle system.



    High Speed  8 Colors 1000mm  Flexo Printing Machine For Pe Activities 4

    Up and down plate

    Adopt the hydraulic pressure rising and down the printing plate automatically
