High Speed Automatic Double Layer Three-side Sealing Bag Making Machine

High Speed Automatic Double Layer Three-side Sealing Bag Making Machine

    • High Speed Automatic Double Layer Three-side Sealing Bag Making Machine
    • High Speed Automatic Double Layer Three-side Sealing Bag Making Machine
    • High Speed Automatic Double Layer Three-side Sealing Bag Making Machine
  • High Speed Automatic Double Layer Three-side Sealing Bag Making Machine

    Product Details:

    Place of Origin: Shanghai
    Brand Name: Printyoung
    Certification: CE
    Model Number: WFD720

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Packaging Details: Neutral packaging, suitable for shipping in a solid iron frame composite box or fumigation wooden box, to adapt to climate change, Fang Lin, moisture, mold, shock, rust.
    Delivery Time: 5-8days (stock),20-60days(unstock)
    Payment Terms: L/C, T/T, Western Union
    Contact Now
    Detailed Product Description
    Machine Type: Bag Forming Machine Driven Type: Electric
    Voltage: 380V Suitable Glue: Water Based Glue
    Web Age Content: Automatic Counting: Aurtomatic
    Packaging Type: Cartons Bag Width: 320—600mm Adjusting According Need
    Roll Material Width: 660—1220mm Paper Roll Max. Dia.: 1200mm
    High Light:

    cloth bag making machine

    ,

    hand bag making machine

       High Speed Automatic Double Layer Three-side Sealing Bag Making Machine



    Quick Detail

    WFD720 multi layer paper bag making machine use for produce 70-140 gsm rolling kraft paper bag, the size can be adjust as user’s need. The middle seam gluing. The bag made by this machine use for packing gain,chemical products, cement.



    Model WFD720
    Bag length unlimited
    Bag width 320—600mm adjusting according need
    Roll material width 660—1220mm
    Paper roll Max. di 1200mm
    Paper weight 70—140gsm
    Roll paper core dia Ф76mm
    Paper layer 1 - 4 layer(according to user’s need, can make 3 layer paper+ 1 film
    Control mode touch screen PLC servo control system,photoelectric tracking
    Out dimension 14000mm*2300mm*1900mm



















































    Process Chart



    High Speed Automatic Double Layer Three-side Sealing Bag Making Machine 0

    Rolling material → unwinding → Layering →middle seam gluing →forming→multi layer traction→ cutting(set length)→pull cutting → photoelectric counting → bag conveying → finished bag.



    Key Feature



    High Speed Automatic Double Layer Three-side Sealing Bag Making Machine 1

    With human-machine interface (touch screen), frequency control, high precision servo control system, PLC programming control system, automatic counting, output and so on. Control system easy and convenient to operate: roll material machine automatically stop; Color code automatic tracking, gluing, forming, feeding material, Photoelectric sensor; setting-length without change gear, cutter with hot and cold dual-use cut off, and other functions.



    Application

    The machine is used for cement bag ,chemical bag.



    Samples

    High Speed Automatic Double Layer Three-side Sealing Bag Making Machine 2

    High Speed Automatic Double Layer Three-side Sealing Bag Making Machine 3
