2 Color Flatbed Offset Printing Machine with Numbering and Perforating

China 2 Color Flatbed Offset Printing Machine with Numbering and Perforating supplier
2 Color Flatbed Offset Printing Machine with Numbering and Perforating supplier 2 Color Flatbed Offset Printing Machine with Numbering and Perforating supplier 2 Color Flatbed Offset Printing Machine with Numbering and Perforating supplier

Large Image :  2 Color Flatbed Offset Printing Machine with Numbering and Perforating

Product Details:

Place of Origin: China
Brand Name: Printyoung
Certification: CE
Model Number: PRY2660E

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: T/T or western Union
Supply Ability: 30 sets per month
Contact Now
Detailed Product Description
Machine Speed: 12000s.p.h Maximum Sheet Size: 540×660mm
Minimum Sheet Size: 273×393mm Sheet Thickness: 0.06-0.6mm
Maximum Image Area: 528×650mm

2 Color Flatbed Offset Printing Machine with Numbering and Perforating



Quick Detail

2 color offset machine with numbering and perforating adopts the swing-down front lay ,swing-down sheet transfer hand and front sheet transfer roll ,enable that the paper has sufficient positioning time



Specifications

Model

PRY2660E

Machine speed

12000s.p.h

Maximum sheet size

540×660mm

Minimum sheet size

273×393mm

Sheet thickness

0.06-0.6mm

Maximum image area

528×650mm

Plate size

677×675×0.3mm

Blanket size

740×680mm

Maximum feeder pile height

940mm

Maximum delivery pile height

780mm

Machine overall dimension

5400×2470×1950mm

Total power of motors

13.2kw

Weight

10700kg



Features

  1. The transfer system consists of the swing-down front lay, the swing-down gripper and transfer cylinder, which ensures adequate positioning time and stability of paper delivery with high-speed.
  2. The impression cylinder and transfer drum are each double diameter, which reduce the times of sheet take-over between print units.
  3. The plate cylinder can be adjusted in the circumferential direction, lateral direction and diagonal direction.
  4. The application of pneumatic technology to the press is one of the press characteristics. Air cylinder for water form roller throw-off mechanism and air cylinder for ink form roller throw-off mechanism are accomplished with Pneumatically-operated valves.
  5. There are five rollers on the plate cylinder. There is an intermediate roller in Alcoholic damping system, which eliminate the “ghost” image, achieve the quick ink-water balance and reduce paper consumption.
  6. The plate is mounted by using the register pin arrangement, which can shorten time of install and check plates.
  7. There are 21 zones in split (staggered) ductor. The press memory or job memory card (disk) contains the current job. Changes and settings made to the current job are transferred to the press. While in printing mode, you can enter the presetting values for next job into the press memory or stored to a disk.
  8.  There is an special lubrication system on the driven side, which can lubricate gear in high-speed running and take away the heat when the gears mesh, and can send auto-alarm signal when there is not enough oil in pump.

Detals of Image

2 Color Flatbed Offset Printing Machine with Numbering and Perforating         2 Color Flatbed Offset Printing Machine with Numbering and Perforating

        Feeder                                                                     Printing Unit

rotary type air valve with automatic removal       sprayed stainless steel impression cylinder

manual paper skew adjustment                          strong corrosion resistance
