Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw

Basic Information
Place of Origin: China
Brand Name: PRINTYOUNG
Certification: CE
Model Number: Pry-750
Minimum Order Quantity: 1 Set
Packaging Details: Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 30 Set/Sets per Month
Voltage: 380V Dimension: 1350*1500*1600mm
Weight: 2000kg Warranty: 1 Year
Production Capacity: 26±2strokes/min Key Selling Points: High-accuracy
Max. Workable Width: 750*520mm Motor Power: 2.2 Kw-6H
Max. Rule Length: <15m
High Light:

Pizza Box Paper Die Cutting Machine

,

Die Cutting Machine 26strokes/Min

,

Paper Die Cutting Machine 2.2kw

Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 0
                                                            PRY-750 Puzzle Die Cutting Machine

Features
1, Sliding bearings are made of high quality alloy cooper,thus to get effect of anti-frietion and shake reducing.
2, Flywheel is with big moment of force and large pressure.
3, High strength due to one piece casting by using top-ranking material for machine body.
4, High strength duo to integral casting with high quality steel.
5, Single plate electromagnetic clutch is sensitive and reliable safety.
6, Single pressing ,continuous pressing, adjustable delay pressing available.
7, Operational height is reasonable arranged ,the opening angle of moving bed is optimum.
8, Reliable performance of safety protection system.
9, Inner and outer movable frame can be fitted, automatic oil pump matching.
Technical Parameters
PRY-750 Puzzle Die Cutting Machine
Model&size
Inner chase size
speed
Max. rule length
Motor power
Machines weight
Overall dimensions
ML1800
1800*1300mm
13±2strokes/min
<60m
11kw-6H
14000kg
2980*2300*2500mm
ML1600
1600*1250mm
13±2strokes/min
<50m
11kw-6H
12000kg
2780*2300*2400mm
ML1500
1500*1040mm
15±2strokes/min
<48m
5.5kw-6H
7500kg
2550*2100*1800mm
ML1400
1400*1000mm
15±2strokes/min
<45m
5.5kw-6H
6800kg
2450*2100*1800mm
ML1300
1300*920mm
15±2strokes/min
<40m
5.5kw-6H
6200kg
2350*2100*1700mm
ML1200
1200*820mm
20±2strokes/min
<35m
4kw-6H
4800kg
2000*2100*1750mm
ML1100
1100*800mm
20±2strokes/min
<35m
4kw-6H
4500kg
1950*2100*1750mm
ML1040
1040*720mm
23±2strokes/min
<30m
4kw-4H
3500kg
1750*2000*1650mm
ML930
930*670mm
23±2strokes/min
<25m
4kw-4H
3000kg
1650*1850*1650mm
ML750
750*520mm
26±2strokes/min
<15m
22kw-6H
2000kg
1350*1500*1600mm
Configuration
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 1 Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 2
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 3 Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 4

Introduction

This machine is a special equipment for creasing and cutting ordinary cardboard, corrugated board, plastic and leather in general, it is applicable for printing packaging decoration and plastic industries. The machine is characterized by its compact structure, fine workmanship, high precision and easy and reliable operation.etc.
Applications
It suits for pre-coated film, and it is widely used for magazines, paper, books and packs for food, medicine, cutting ordinary cardboard, corrugated board, plastic and leather in general, it is applicable for printing packaging decoration and plastic industries. cosmetic and so on.
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 5
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 6
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 7
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 8
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 9
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 10
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 11
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 12
Pizza Box Paper Die Cutting Machine 26strokes/Min 2.2kw 13

Q1: Are you a manufacturer or a trading company?

A: Our shanghai office is mainly doing export. We have our own factory in Wenzhou, Zhejiang Province.

Q2. What is the machine warranty?

A: One year. After the warranty, we still provide technical support to buyer at low cost.

Q3. What is the production time while placing order?

A: Normally about 10-20 days.

Q4. What is the delivery time?

A: 15-30days after deposit.

Q5. Can your company handle shipping for customers?

A: Yes, just give us destination sea port or container yard.

Q6. Does the packing strong?

A: Yes. Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included..

Q7. How about the machine installation and training ?

A: 1)We provide training in our factory for free;
2)We can send technicians (engineers) to your factory for installation and training. You shall pay the round trip air fare and accommodations, plus each technician charges USD100/per day.

Q8. Do you have machines in stock?

A: For standard model, we have a large quantity in stock. For special model, we need 20-30 days to produce it for you.

Q9. How can you assure the machines’ quality?

A: Each machine will be test running at least 24 hours before delivery to assure the quality. And during the warranty, we will give spare parts for free if machine has any problem.

Q10. Do you inspect machines or test running before packing?

A: Of course we do. We have QC department to debug the machine before packing. If you want to use specific material to do the test running, you need to pay for the cost of the material

Q11. What’s the payment term?

A: T/T 50% in advance, the balance shall be paid before delivery. We also accept payment by West Union or L/C at sight.

Q12. Do you accept factory visiting?

A: Warmly welcome for your visiting.

Q13. How many years are you in printing field?

A: Shanghai company is 12 years old, the factory is more than 20years.

Q14. How many clients do you have?

A: We have sold our machines to about 60 countries. We have agents in South Africa, Morocco and Italy.
